UT-ONE B03A is accurate and versatile 3 channels thermometer readout. UT-ONE B03A is capable of measuring platinum resistance thermometers, thermistors and thermocouples. Optionally, an ambient combined probe may be used for the measurement of ambient conditions (air temperature and relative humidity). UT-ONE B03A features a color touch screen which presents measured data in graphical and numerical format. UT-ONE B03A can be operated in a stand-alone mode or connected to the computer via the serial or USB interface. UT-ONE B03A can be battery-operated from the internal LiPo battery, which provides up to eight hours of standalone operation.
Available Options:
- Ambient conditions probe - used for the measurement of ambient conditions (air temperature - TA and relative humidity - RH). It can be connected to the 4-pole circular connector located above the touch screen directly or indirectly with the 2 m extension cable.
- Plastic Carrying Case
Batemika UT-ONE B03A 3-Channel Thermometer Readout PRT TC
Lead Time
Contact us for any questions about this product.
Please allow 4-6 weeks lead time for new product to arrive.All new items for American customers will arrive FOB. Any taxes or tariffs will be covered.
Technical Data
Technical data Channels:
3, consecutive
Acquisition time per channel:
2 to 240 s
Probe Types:
PRT, Thermistors, Thermocouples
Temperature range:
-200 °C to 1800 °C max, limited by the therm. probe
Cold junction compensation:
Internal, External
Communication interface:
USB and RS232
Display:
3.2” Color LCD 320x240 pixels
DC power supply:
5.9 V, 0.5 A
Power consumption:
1 W typical, 2.5 W max
St. Lipo battery capacity:
2000 mAh, 7.4 Wh
St. batery operation:
8 h (no power save)
Weight (kg):
1.5
Ext. dimensions (WxHxD):
160x100x290 mm
Ambient conditions monitoring:
Optional ext. probe, humidity & temperature
