| Imaging Data |
| IR Resolution |
480 × 640 pixels |
| Thermal Sensitivity / NETD |
<40 mK at 86°F (30°C) |
| Field of View (FOV) |
38 × 49° |
| Minimum Focus Distance |
1.6" (0.5 m) |
| Spatial Resolution (IFOV) |
1.5 mrad |
| F-number |
1.4 |
| Image Frequency |
30 Hz |
| Focus |
Fixed focus |
| Spectral Range |
7.5 to 13 μm |
| Color Palettes |
Iron, White hot, Black hot, Rainbow, Arctic, Lava, Rainbow HC |
| User Interface |
| Display |
5" (12.70 cm) 720 × 1280 color LCD |
| Touch Screen |
Capacitive touch |
| Text |
Text annotation on image using onscreen keyboard |
| Flashlight |
Manually activated bright LED |
| Image Adjustment |
Automatic/Manual |
| Laser Pointer |
| Laser |
Class 2 |
| Laser Alignment |
Position of laser pointer automatically displayed on the infrared image |
| Image Presentation Modes |
| Image Modes |
MSX, Thermal, Picture-in-Picture, Digital camera |
| Measurement |
| Temperature Range |
-4 to 392°F (-20 to 200°C)
50 to 842°F (10 to 450°C) |
| Accuracy |
±2°F (±1°C) or ±2% |
| Measurement Analysis |
| Spotmeter |
Center spot, box with minimum/maximum |
| Isotherm |
Above, Below |
| Delta T |
Yes, NFPA 70B compliant |
| Emissivity Correction |
Variable from 0.01 to 1.0 |
| Emissivity Table |
Predefined materials |
| Measurements Correction |
Emissivity, matt/semi-matt/semi-gloss + custom value, reflected apparent temperature, atmospheric compensation |
| 1-touch Level/Span |
Yes, automatic contrast |
| Storage of images |
| File Formats |
Standard JPEG, 14-bit measurement data included |
| Storage Media |
Internal memory, onboard Flir Ignite cloud and Asstetink connectivity |
| Digital Camera |
| Resolution |
8 MP, Autofocus |
| FOV |
50.5 × 64.5° |
| Data Communication Interfaces |
| Cellular |
No |
| Interfaces |
Display port over USB-C |
| Wi-Fi |
IEEE 802.11 a/b/g/n (2.4 and 5 GHz) |
| Radio |
| Operating Frequency |
WLAN 2.4 GHz: 2412 to 2462 MHz
WLAN 5 GHz: 5150 to 5250 MHz |
| Power Supply |
| Battery Type |
Rechargeable Lithium-ion battery |
| Battery Operating Time |
4 hours at 77°F (25°C), ambient temperature and typical use |
| Charging System |
Battery is charged inside the camera or in specific charger (included) |
| Charging Time |
2 hours in charger / 4 hours to 90% capacity in-camera |
| Power Management |
Automatic shut-down |
| AC Operation |
Optional accessory: 45 W AC adapter, 100 to 240 V AC input, 15 V DC, 3 A output to camera |
| Environmental and Certifications |
| Drop Test |
6' (2 m) |
| Encapsulation |
IP54 (IEC 60529) |
| Operating Conditions |
5 to 122°F (-15 to 50°C)
95% relative humidity |
| EMC |
EN 301 489-1, EN 301 489-17, EN 61000-6-3, EN 61000-6-2, FCC 47 CFR Part 15 Class B |
| Radio Spectrum |
ETSI EN 300 328, ETSI EN 301 893, FCC 47 CFR Part 15, RSS-247 |
| Shock |
25 g (IEC 60068-2-27) |
| Vibration |
2 g (IEC 60068-2-6) |
| Physical data |
| Dimensions |
8.9 × 2.9 × 2.9" (225 × 136 × 73 mm) |
| Weight |
1.76 lbs (0.8 kg) |
