UNI-T UPO1152HD 12-Bit 150MHz 2Ch High Definition Oscilloscope

Please allow 2-3 weeks lead time for new product to arrive.

• 150 MHz Bandwidth – Ideal for high-speed embedded, analog, and power validation
• 2 Analog Channels – Streamlined form factor with dual-channel precision
• 12-bit Vertical Resolution – Capture subtle detail with 16× the resolution of 8-bit scopes
• 1.25 GSa/s Sample Rate – Supports accurate measurement of fast edges and clocks
• 100 Mpts Memory Depth – Long waveform capture at full speed and resolution
• Ultra Phosphor 3.0 – Up to 1,000,000 wfms/s with 256-color intensity grading
• Integrated Power Analysis – Built-in ripple, harmonics, SOA, switching loss, and more
• 1M-point FFT – Full-spectrum view with waterfall and peak markers
• Protocol Decoding – UART, I²C, SPI, CAN, LIN with trigger and event view
• 6-in-1 Functionality – Oscilloscope, spectrum analyzer, DVM, counter, logic/protocol tools
• USB-C PD Input – Compatible with portable and benchtop power setups
• Remote Access – Control via SCPI, browser, or automated scripts

Parameter	UPO1152HD Specification
Bandwidth	150 MHz
Channels	2 analog
Sampling Rate	1.25 GSa/s (1CH), 625 MSa/s (2CH)
Vertical Resolution	12-bit (16-bit with ERES)
Memory Depth	100 Mpts
Capture Rate	Up to 1,000,000 wfms/s
Display	7" 1024×600 capacitive touchscreen
Interfaces	USB Host/Device, LAN, HDMI, AUX Out
Power	USB-C PD (≥12 V/3 A)
Weight	1.56 kg

Package Contents

• UPO1152HD Oscilloscope
• 2 × UT-P05 Passive Probes (200 MHz)
• USB 2.0 Cable (UT-D14)
• Type-C PD Power Adapter
• User Manual & Calibration Certificate

Optional Accessories

• UT-ISOT Isolation Transformer
• UT-DF01 Deskew Fixture
• UT-P21 High Voltage Probe (15 kV)
• UT-P4030D High-Frequency Current Probe (100 MHz)
• UT-P4150 Current Probe (150 A/30 A, 12 MHz)
