Ultra-portable. Ultra-broadband. The Spectrum Master™ MS276xA family of ultraportable spectrum analyzers is the first solution of its kind to provide continuous coverage to 170 GHz. This family now offers:
- The Spectrum Master MS2760A models: providing full broadband coverage from 9 kHz to 170 GHz with excellent dynamic range and DANL performance.
The Spectrum Master MS2760A delivers the best-in-class price/performance ratio unmatched by traditional benchtop instruments. The Spectrum Master™ MS276xA series are pocket-sized, yet big on performance with leading dynamic range, sweep speed, and amplitude accuracy. The ultraportable size of these instruments enables a direct connection to almost any DUT, eliminating the need for lossy, expensive cables. This enables you to more efficiently advance your technology development and reduce your time to market.
Utilizing Anritsu’s patented nonlinear transmission line (NLTL) technology – the same technology that Anritsu’s world-class vector network analyzers use – the 145 GHz and 170 GHz models are the world's first handheld, millimeter-wave spectrum analyzers to provide broadband, continuous coverage from 9 kHz to 170 GHz and break through the 110 GHz barrier. Having frequency coverage in to the higher bands enables research and development in the entire D band spectrum as well as advanced millimeter-wave applications like radio astronomy, automotive radar, antenna beam pattern testing, and more.
The Spectrum Master MS276xA family are all USB-powered and controlled from a Windows-based PC, laptop, or tablet, making them uniquely flexible for use in the lab, on the manufacturing floor, or even in the field.
| Models | Description |
| MS2760A-0032 | 9 kHz to 32 GHz Spectrum Master, ultraportable spectrum analyzer |
| MS2760A-0044 | 9 kHz to 44 GHz Spectrum Master, ultraportable spectrum analyzer |
| MS2760A-0050 | 9 kHz to 50 GHz Spectrum Master, ultraportable spectrum analyzer |
| MS2760A-0070 | 9 kHz to 70 GHz Spectrum Master, ultraportable spectrum analyzer |
| MS2760A-0090 | 9 kHz to 90 GHz Spectrum Master, ultraportable spectrum analyzer |
| MS2760A-0110 | 9 kHz to 110 GHz Spectrum Master, ultraportable spectrum analyzer |
| MS2760A-0145 | 9 kHz to 145 GHz Spectrum Master, ultraportable spectrum analyzer |
| MS2760A-0170 | 9 kHz to 170 GHz Spectrum Master, ultraportable spectrum analyzer |
Anritsu MS2760A Ultraportable Spectrum Analyzer
- Frequency Ranges: 9 kHz to 9 GHz, 13 GHz, and 20 GHz
- Measurements: Occupied Bandwidth, Channel Power, ACPR, C/I, Emission Mask, Spurious Emissions, Field Strength
- 3G and 4G Measurement options for LTE (FDD & TDD), CDMA, W-CDMA, WiMAX, GSM, and
TD-SCDMA - Interference Analyzer: Spectrogram, Signal Strength, RSSI, Mapping
- Dynamic Range: > 106 dB in 1 Hz RBW @ 2.4 GHz
- DANL: –164 dBm in 1 Hz RBW @ 1 GHz preamp On
- Phase Noise: –112 dBc/Hz @ 10 kHz offset at 1 GHz
- 1 Hz to 10 MHz Resolution Bandwidth (RBW)
- Tracking Generator up to 20 GHz
- PIM Hunting
- PIM Alert (a downloadable easyTest™ script)
- Standard three-year warranty (battery one-year warranty)
Options Description MS276xA-0097 Accredited Calibration to ISO17025 and ANSI/NCSL Z540-1, includes calibration certificate, test report, and uncertainty data MS276xA-0098 Standard Calibration to ISO17025 and ANSI/NCSL Z540-1, includes calibration certificate MS276xA-0099 Premium Calibration to ISO17025 and ANSI/NCSL Z540-1, includes calibration certificate, test report, and uncertainty data
