HT Instrument MERCURY is a TRMS digital multimeter capable of measuring AC/DC voltage up to 1000V, AC/DC current up to 10A as well as resistance, continuity test, diode test, frequency, capacitance and temperature with K-type probe.
Other major functions include AC+DC mode taking into account DC components overlapping AC signals and current measurement with standard and flexible transducer clamps (provided accessory F3000U). A camera with 80x80pxl resolution is built inside to get simultaneous readings of thermal and electrical values for the item under test.
MERCURY is provided with Data Logger function capable of carrying out and saving recordings of every parameter as well as displaying the values’ diagram. Snapshots can be saved into BMP format inside a micro SD card supplied as accessory and Bluetooth permits connection with mobile devices (tablet/smartphone) through HTMercury APP creating reports to share measuring results.
The instrument was designed in compliance with safety standards IEC/EN61010-1 with double insulation protection according to CAT IV 600V or CAT III 1000V. MERCURY is equipped with analogue bargraph LCD and each function can be selected by rotary switch. Additional functions include HOLD to keep displayed data, MAX/MIN, PEAK and Auto Power OFF to save the internal rechargeable battery.
HT Instruments MERCURY TRMS DMM Multimeter w/IR Camera, 1000VDC, 10A Resistance
Ordering Information
Please allow 4-5 weeks for this product to arrive.
Includes 1 year manufacturer warranty.
Specifications
DC voltage Measuring range 0.1mV ÷ 1000V Resolution 0.1mV ÷ 1V Basic accuracy ±(0.2%reading + 5digits) AC TRMS, AC+DC TRMS voltage Measuring range 1mV ÷ 1000V Frequency range 50Hz ÷ 1kHz Resolution 1mV ÷ 1V Basic accuracy AC voltage ±(0.8%reading + 5digits) Basic accuracy AC+DC voltage ±(2.0%reading + 20digits) AC TRMS current with flexible clamp F3000U Measuring range 0.01A ÷ 3000A Basic resolution 0.01A ÷ 1A Frequency range 50Hz ÷ 1kHz Accuracy ±(1.0%reading + 5digits) DC current Measuring range 0.1μA ÷ 10A Resolution 0.1μA ÷ 0.01A Accuracy ±(1.0%reading + 3digits) AC, AC+DC current Measuring range 0.1μA ÷ 10A Basic resolution 0.1μA ÷ 0.01A Frequency range 50Hz ÷ 1kHz Basic accuracy ±(1.2%reading + 5digits) Resistance and Continuity test Measuring range 0.1Ω ÷ 60MΩ Resolution 0.1Ω ÷ 0.01MΩ Basic accuracy ±(0.5%reading + 5digits) Buzzer test R<50Ω Frequency (electronic circuits) Measuring range 0.01Hz ÷ 10MHz Resolution 0.01Hz ÷ 0.01MHz Basic accuracy ±(0.09%reading + 5digits) Frequency (electronic circuits) Measuring range 40Hz ÷ 10kHz Resolution 0.01Hz ÷ 0.001kHz Accuracy ±0.5%reading Duty Cycle Measuring range 0.1% ÷ 99.9% Resolution 0.1% Accuracy ±(1.2%reading +2digits) Diode test Maximum test current 1.5mA Temperature with K-type probe Measuring range -40°C ÷ 1000°C / -40°F ÷ 1800°F Resolution 0.1°C ÷ 1°C / 0.1°F ÷ 1°F Accuracy 1.5%reading + 3°C / 1.5%reading + 5.4°F Capacitance Measuring range 0.01nF ÷ 6000μF Resolution 0.01nF ÷ 1μF Basic accuracy ±(1.2%reading + 8digits) Datalogger function Max number of recordings which can be saved in the internal memory 16 Selectable sampling interval 1s ÷ 15min Max selectable duration of recordings 1s ÷ 10h IR camera function Sensor resolution 80 x 80pxl Temperature measuring range -20°C ÷ 260°C / -4°F ÷ 302°F Sensitivity <0.1°C (@ 30°C) Visual range (FOV) 21° x 21° Focusing / Lens automatic / 7mm Image frequency 50Hz General characteristics Instrument safety IEC/EN61010-1 EMC IEC/EN 61326-1 Insulation double insulation Pollution level 2 Measurement category CAT IV 600V, CAT III 1000V Functions Data HOLD, MAX/MIN/PEAK,REL, Laser, Bluetooth, LED illuminator Memory for data saving micro SD card, BMP format Mechanical characteristics Size (L x W x H) 185 x 75 x 55mm Weight (batteries included) 555g Mechanical protection IP65 Power supply Battery type 1x7.4V rechargeable Li-ION battery, 2300mAh Auto power off 15,30,60min (selectable) Display Type of display 4 dgt LCD, max 6000 dots, decimal sign, point Updating frequency 3 times/s Conversion TRMS Tech Specs
Multimeters Template
Type Digital Style Hand-Held Measures AC V Yes Measures DC V Yes True RMS Yes Basic Accuracy V DC ±(0.2%reading + 5digits) Backlight Yes Frequency Yes Temperature Yes CAT Rating III CAT Voltage 1,000 V, 600 V Duty Cycle % Measuring range: 0.1% ÷ 99.9%
Resolution: 0.1%
Accuracy: ±(1.2%reading +2digits)Features
- Data logger function and real-time display of graphs of measured data
- DC, AC TRMS, AC+DC TRMS voltage up to 1000V
- DC, AC TRMS, AC+DC TRMS current up to 10A
- DC, AC TRMS, AC+DC TRMS current by means of external clamp transducer
- Measurement of frequency and duty cycle
- Resistance and buzzer for continuity test
- Measurement of capacitance
- Diode test
- Temperature measurement by means of external K-type probe
- MAX/MIN/PEAK/HOLD/REL functions
- Selectable sampling rate: from 1s to 15min
- Built-in white-light torch
Included Accessories
- F3000U Flexible clamp with full scale 30/300/3000A AC
- 4413-2 Couple of red/black 4mm, 90° professional test leads
- BATMCY Spare part Li-ION battery 7.4V 1500mAh
- A0MCY Adapter multiplug for MERCURY with base charger
- Micro SD card 8GB,10x
- B0MCY Carrying case
- Alkaline battery type AAA IEC LR03, 2pcs
- Type K bead probe + adapter
- User manual
- Calibration certificate ISO9000
