EX Series Single Output products are high-performance and high-efficiency programmable DC power supply with RS232C, RS485, USB, TCP/IP(option) interface based on SCPI (Standard Commands for Programmable Instruments) protocol and the combination of bench-top and system features in these power supplies provides versatile solutions for your design and test requirements in the industrial fields, R&D institute center and education fields.
Available in 1U Size(600W~2.5KW), 2U Size(3.75W~5KW), and 4U Size(6KW~10KW)
EX50-72 2U Output
Voltage: 0 to 50.0 Maximum 52.5
Current: 0 to 72.0 Maximum 75.6
Output WATT: 4.0kW
ODA EX50-72 2U Switching Type Programmable DC Power Supply 50V 72A 4kW 4000W
Get a Quote
Contact us for a quote or any questions about this product.
Please allow 4-6 weeks lead time for this new item to arrive.
Features
- 4-Digit Display Resolution
- 16×1 Big-Char Type LCD Display attached
- Adjustment encoder provided for voltage and current
- OVP (Over Voltage Protection), OCP (Over Current Protection) Protection Mode provided
- UVL (Under Voltage Lock), OVL (Over Voltage Lock), UCL (Under Current Lock), OCL (Over Current Lock)
- Calibration function provided (manual and PC)
- Panel Lock function provided
- Memory Store & Recall function provided (It is possible to store and recall 10)
- Output ON/ OFF function provided
- Limit Display function provided
- 11 diverse Factory Modes provided
- RS-232C, RS485, USB Communication mode is basic(TCP/IP communication is optional)
- Single phase, AC Input 220VAC ±10% and 3 phase AC Input
Accessories & Options
Accessories
– AC Power Cord(Type F)
– Operating Manual(QR Code)
– Demo software program(QR Code)Options
– RS-232C cable
– RS- 485 cable
– TCP/IP communication
– Output ON/OFF signal control
– Analog Programing(Vout & Iout voltage programming) & Monitoring(Output Voltage & Current Monitoring) by 0~5V or 0~10V, Isotated type
– AC Power Cord(Other type)
– AC Input 380V or 400V± 10%, 3-phase 4-wire system(R,S,T,N,G), 50~60Hz
– AC Input 200V or 220V± 10%, 3-phase 3-wire system(R,S,T,G), 50~60Hz
