The 9010+ Multifunction Calibrator from Meatest is designed as a universal calibration tool for electrical calibration laboratories, covering most of their workload like multimeters clamp meters, ohm meters, power meters and power analyzers, energy meters, transducers, insulation testers, process meters, scopes and many others.

High load capacity of both voltage (up to 50 mA) output allows for calibration of high-consumption analogue meters. Installed harmonic and non-harmonic shape signals allow for testing meter sensitivity to distorted signals by a signal with various crest factor.

Advancing from previous M14x calibrator series, 9010+ can now calibrate even 400 MHz/1.1 GHz scopes, 1.5 kV insulation testers and power meters. On the other hand we kept all the popular functions including complete transducer and external sensor calibration (strain gauge, pressure, torsion, strength, etc.) using the built-in multimeter, automatic uncertainty calculation, remote control and easy recalibration.

This is similar to the Fluke 5500A series of calibrators such as Fluke 5522A.

Coils for clamp meter calibration up to 1500A are available for purchase to boost the current output.

This item comes standard with factory calibration certificate, user manual, standard power cable, red/black test leads, and USB cable.

Available Options:
SCO Scope extension 400 MHz & 1.1GHz for calibrating oscilloscopes.
HVR High voltage resistance extension 1.5 kV for calibrating insulation testers.
MER Process Multimeter extension
9010-60 Cable adapter for R4W/RTD input
91 Pt 100 cold junction compensator
CALIBER Calibration Software

This calibrator is similar to a Fluke 5500A and other industry standard calibraton products.
