Models available are:
745T-20C-100ps Resolution
745T-20C-1ps Resolution

The Model 745T-20C Digital Delay Generator provides users with an amazing twenty independent channels of pulse delay and width. This multi-channel Digital Delay Generator provides delay resolution of 100 picoseconds (ps) with an optional 1 picosecond (ps) resolution. The jitter is less than 25 ps with internal or external triggers.

The Model 745T-20C delivers up to 6 V into 50 Ω, meeting all TTL applications. The levels are adjustable on a channel-by-channel basis giving you complete time and amplitude domain control. The fast outputs, with risetimes of 1 ns, are on the rear panel for an elegant look for complex experiments. The front panel controls are accessed by a touchscreen interface with several programming options (Ethernet, etc) for remote control.

All parameters (delay/amplitude/width/trigger) may also be controlled with an embedded GUI that opens in an HTML browser such as Internet Explorer, Firefox, or Chrome at 10 or 100 Mb/s rates.
The Model 745T-20C is uniquely suited to gate, delay, pulse and synchronize many experiments in the nanosecond and picosecond domain. The space saving, reduced calibration costs, and simple control of so many channels are ideal for users of multiple channels of timing.
