The LNS-18 is a general purpose synthesizer that exhibits the best phase noise performance of the industry. Its low noise oscillators generate a very flexible frequency up to 18 GHz. With -132 dBc/Hz at 10 GHz carrier and 20 kHz offset, the LNS-18 can help you challenge tomorrow’s requirements for Space and Defense applications.
Many options are available in addition to the Ethernet and EFC input.
| FREQUENCY | |
|---|---|
| Frequency Output : | 4 to 9 (LNS-9) or 18 (LNS-18) GHz (option for lower frequencies) |
| Output Level : | +12 dBm (± 2 dB) |
| Non-Harmonic spurious : | 1/f3 slope from 1 Hz to 1 kHz offset & <-70 dBc above 1 kHz offset typically |
Absolute Phase Noise (dBc/Hz)
| TYP. DBC/HZ VS OFFSET (HZ) | 10 HZ | 100 HZ | 1 KHZ | 10 KHZ | 100 KHZ | 1 MHZ | 10 MHZ |
|---|---|---|---|---|---|---|---|
| 4GHz | -62 | -94 | -126 | -138 | -140 | -142 | -165 |
| 8GHz | -56 | -88 | -120 | -132 | -135 | -138 | -162 |
| 16GHz | -50 | -82 | -114 | -126 | -129 | -132 | -155 |
Noise XT LNS-18 Ultra Low Noise Synthesizer Noise Floor -132 dBc/Hz
Order Info
Please contact us for a quote or more information about this product.
info@stratatek.com or (905) 406 - 0100Features
- Lowest noise floor : -132 dBc/Hz @20 kHz for a 10 GHz output!
- 7 » Touch Screen
- Optional Level Control
- Optional Pulse Modulation
- Optional GPIB port
- Optional Low Frequency extension down to 8 MHz
- Optional 10 MHz ultra stable time-base
- Optional 1 mHz resolution
Options
- LNS-1HZ: 1 mHz resolution
- LNS-LF: Output frequency divider
- LNS-PULSE: Pulse modulation
- LNS-10M: 10 MHz stable time base
- LNS-GPIB: GPIB port
